电场探头?HI-4433-STE电场探头
ETS-Lindgren的HI-4433-STE型电场探头测量电场强度并提供X,Y和Z以及总场值。
ETS-Lindgren的HI-4433-STE型电场探头测量电场强度,并提供X,Y和Z以及总场值。每个轴的数据可以单独查看或总结。现场探头光纤耦合到读出或PC接口,以消除电缆干扰的可能性。
对于其他频率和数据范围,ETS-Lindgren的HI-4433系列宽带射频(RF)各向同性场探头采用电池供电,专为进行RF暴露测量而设计。
ELECTRIC FIELD PROBES HI-4433-STE Electric Field Probe
ETS-Lindgren’s?Model?HI-4433-STE Electric Field Probe?measures electric field strength and provides X, Y and Z as well as total field values.
ETS-Lindgren’s?Model?HI-4433-STE Electric Field Probe measures electric field strength and provides X, Y and Z as well as total field values. Data from each axis can be viewed individually or summed. The field probe is fiber optically coupled to the readout or PC interface to eliminate the possibility of cable interference.
For additional frequencies and data ranges, ETS-Lindgren’s HI-4433 Series of ??Broadband Radio Frequency (RF) Isotropic Field Probes are battery-operated and designed for use in making RF exposure measurements.???
主要特点
- 各向同性电场感应:500 kHz至5 GHz
- 自动连续归零
- 光纤技术
- 每个轴的数据可以单独查看或总结
- 适用于??HI-4416读数器,HI-4413P??光纤转RS232转换器或HI-4413USB光纤转USB转换器
- ProbeView LT软件可免费下载
产品规格
电气规格
频率响应:?500 kHz至5 GHz,+ 2.0 / -3.0 dB
物理规格
湿度:??5到95%相对湿度无冷凝
其他规格
- 探针和电子外壳
- 快速电池充电器
- 电介质手柄
- 2米光纤电缆
- 校准证书
- 用户??手册
产品图表

Graphs for Uploading

Graphs for Uploading
Key Features
- Isotropic Electric Field Sensing: 500 kHz to?5 GHz
- Automatic Continuous Zeroing
- Fiber Optic Technology
- Data from Each Axis can be Viewed Individually or Summed
- For Use with?HI-4416 Readout, HI-4413P?Fiber to RS232?Converter or HI-4413USB Fiber to USB Converter
- ProbeView™ LT Software Available for Free Download
Specifications
Electrical Specifications
Frequency Response: 500 kHz to 5 GHz, +2.0/-3.0 dB
Physical Specifications
Humidity:?5 to 95% Relative Humidity Non-condensing
Other Specifications
- Probe and Electronics Housing
- Fast Battery Charger
- Dielectric Handle
- 2 Meter Fiber Cable
- Calibration Certificate
- User?Manual
Product Charts

Graphs for Uploading

Graphs for Uploading
