如果质量和可靠性影响您的输出，那么新的Tinsley“Q”仪表可能只是适合您的产品。Tinsley 5867“Q”表设计用于利用任何卷绕组件的电子特征，实际上是一种快速操作且灵敏的电感和电阻表，可用于比较几乎任何类型的绕组。可以可靠地测试线圈，电机转子和定子或变压器。操作简单，可选择使用内部可充电电池，“Q”仪表同样适用于生产区域和现场。对于先前分配了签名值的伤口组件，可以在制造过程的各个阶段中使用它来识别在组件完成之前指示潜在故障的变化。
或者，如果在电机和发电机等机器的计划维护期间使用，它将在发生故障之前识别发展中的故障。
If quality and reliability is affecting your output then the new Tinsley “Q” Meter may be just the product for you. Designed to exploit the unique electrical signature of any wound component, the Tinsley type 5867 “Q” Meter is in fact a fast operating and extremely sensitive inductance and resistance meter which can be used to compare almost any type of winding. Coils, motor rotors and stators or transformers can be reliably tested. Being simple to operate and with an option to operate from an internal rechargeable battery, the “Q” Meter is equally at home in the production area and in the field. With wound components previously assigned a signature value it can be used in various stages of the manufacturing process to identify changes that indicate a potential failure prior to completion of the component.
Alternatively, if used during planned maintenance of machines such as motors and generators it will identify developing faults before they become a catastrophic failure.
Tinsley 5867型使用缠绕组件的“Q”来指示组件的质量。它用于比较绕组之间的电气特性，在已知的良好示例和被测单元之间或三相装置的相之间。虽然设计用于大型电动机和发电机，但该仪器同样适用于较小的物品，如工业和家用电动机，变压器和交流发电机。
仪器内置可充电电池，可使用内置充电器补充电池。Tinsley 5867操作简单，是制造过程中级间测试的理想选择，可轻松识别短路和其他制造缺陷。它的易用性也使5867成为服务工程师识别现场故障的理想工具。
检测： |
|
The Tinsley type 5867 uses a wound component’s “Q” to give an indication of the quality of the component. It is used to compare the electrical characteristics between windings, either between a known good example and a unit under test or between phases of a three phase device. Although designed for use on large motors and generators the instrument is equally suitable for use with smaller items such as industrial and domestic motors, transformers and alternators.
The instrument has internal rechargeable batteries that can be replenished using the instruments built in charger. Being simple to operate, the Tinsley 5867 is ideal for interstage testing during the manufacturing process and will easily identify shorted turns and other manufacturing defects. Its ease of use also makes the 5867 the ideal tool for service engineers to identify faults in the field.
Detection of: |
|
请参阅下表，了解本产品规格的详细信息。
数字显示 | 8位LED 0.8“高度，范围指示器， |
工作温度? | 0至40°C |
常温? | 20℃下 |
相对。湿度最大? | 80％（非冷凝） |
贮存温度? | -20°C至+ 50°C |
电源连接? | 90 – 260V |
外形尺寸? | 240 x 280 x 120毫米 |
重量? | 4.5千克 |
测量频率? | 250毫秒 |
See the table below for a run-down of this product’s specifications.
Digital display | 8 digit LED 0.8″ height, range indicator, |
Working temperature? | 0 to 40°C |
Normal temperature? | 20°C |
Rel. Humidity max.? | 80% (non-condensing) |
Storage temperature? | -20°C to +50°C |
Mains connection? | 90 – 260V |
Dimensions? | 240 x 280 x 120 mm |
Weight? | 4.5 kg |
Measuring frequency? | 250ms |
